Small-sized screw compressor

Badyar Single-Phase and Three-Phase Screw Compressors – Compressed Air with Domestic Consumption, Industrial Performance This series of compressors not only saves electricity, but also comes with advanced engineering design, high efficiency and easy maintenance.

Highlighted Features:

Compatible with 220 single-phase household electricity, suitable for spaces without three-phase electricity
Inverter technology with high energy efficiency, 50% reduction in consumption compared to conventional motors
IE4motorwith 95%
Soft start With Low Primary Current, no damage to the home power grid
Designed with very low noise and constant pressure for oscillation-free operation
Large air fan with low speed , producing high air volume with long
Six heavy bearings with conical connection (Morse Taper), vibration control within 1mm/s
Isolation technology Exclusive five-stage, reducing oil output to less than 2ppm
Easy installation and maintenance

Suitable for:Small workshops

Repair centers
Home and industrial jobs
Places without three-phase industrial electricity

Badyar; Industrial performance with homeelectricity.

Significantly Reduce Energy Costs With Badyar Permanent Inverter Compressors

In most industries, compressed air consumption fluctuates throughout the day, while only about 10% of applications require a completely constant air supply. This means that, in most cases, traditional compressors consume a lot of energy unnecessarily. Badiyar has provided a suitable solution by analyzing the market and consumer behavior in detail:

Permanent Magnet Screw Compressor with Inverter (VSD)

Smart adaptation to the actual air demand in real time
Reduction in energy consumption 35% to 42% compared to fixed-speed compressors
Supplying compressed air Exactly the quantity needed, without waste
Reduce electricity costs up 70% of the total life cycle cost of the compressor < The life of the device has also been taken into account:
- Equipped with the Oil Temperature Stabilization (ATS) System
- Oil operating temperature after the device turning on
- Preventing
- excessive dropping of the
- output temperature, which causes the formation of distillation and oil emulsion
- Increase the life of the oil and compressor parts by preventing the phenomenon of emulsification
Badyar; <
